Schneider Electric MasterPact NW08H13PEDO6.0P

Original price was: 4,000.00 $.Current price is: 2,000.00 $.

Details:

circuit breaker Masterpact NW08H1 – 800 A – 3 poles – drawout – w/o trip unit

Weight 90000 g
Dimensions 39.5 × 44.1 × 43.9 cm
Add to wishlist

Description

Range MasterPacT
Product name MasterPact NW
Circuit breaker name MasterPact NW08H1
product or component type Circuit breaker
Device application Power distribution protection
Poles description 3P
Control unit Without control unit
[In] rated current 800 A at 40 °C
Performance type H1 65 kA 440 V AC
[Ue] rated operational voltage 690 V AC 50/60 Hz
Suitability for isolation Yes conforming to EN/IEC 60947-2
Selectivity category Category B
Control type Push-button
Mounting mode Drawout



[Icu] rated ultimate short-circuit breaking capacity 65 kA at 220/415 V AC 50/60 Hz

65 kA at 440 V AC 50/60 Hz

65 kA at 525 V AC 50/60 Hz

65 kA at 690 V AC 50/60 Hz
[Ics] rated service breaking capacity 65 kA at 220/415 V AC 50/60 Hz

65 kA at 440 V AC 50/60 Hz

65 kA at 525 V AC 50/60 Hz

65 kA at 690 V AC 50/60 Hz
[Icw] rated short-time withstand current 65 kA 1 s

36 kA 3 s
[Icm] rated short-circuit making capacity 143 kA 220/415 V AC at 50/60 Hz

143 kA 440 V AC at 50/60 Hz

143 kA 525 V AC at 50/60 Hz

143 kA 690 V AC at 50/60 Hz
Sensor rating 400 A

800 A
[Ui] rated insulation voltage 1000 V AC 50/60 Hz
[Uimp] rated impulse withstand voltage 12 kV
Power dissipation in W 100 W
Maximum breaking time 25 ms
Maximum closing response time 70 ms
Mounting support Backplate

Rails
Upside connection Front

Rear
downside connection Front

Rear
Connection pitch 115 mm
Mechanical durability 12500 cycles without maintenance

25000 cycles with maintenance
Electrical durability 10000 cycles 440 V AC 50/60 Hz without maintenance conforming to EN/IEC 60947-2

10000 cycles 690 V AC 50/60 Hz without maintenance conforming to EN/IEC 60947-2

AC-23A: 10000 cycles 440 V AC 50/60 Hz without maintenance conforming to EN/IEC 60947-3

AC-23A: 10000 cycles 690 V AC 50/60 Hz without maintenance conforming to EN/IEC 60947-3

AC-3: 6000 cycles 440/690 V AC 50/60 Hz without maintenance conforming to EN/IEC 60947-3
Height 439 mm
Width 441 mm
Depth 395 mm
net weight 90 kg
Standards EN/IEC 60947-1

EN/IEC 60947-2
Product certifications CE

CCC

EAC
